The Shimano Deore FD-M612 front derailleur is the perfect choice for modern 3x10-speed MTB groupsets. Equipped with innovative Side-Swing technology, it ensures particularly light and efficient shifting operations – even under high loads or in technically demanding terrain.

Thanks to Direct Mount (D-Type), the front derailleur is easy to install and ideally suited for frames with short seat tubes. The optimized cable routing improves shifting power transmission and noticeably reduces the effort required for shifting.

Highlights:

• Side-Swing Technology: Improved shifting performance and more tire clearance
• Mounting: Direct Mount (D-Type) for modern MTB frames
• Cable Routing: Front Pull
• Compatible with: Shimano 3x10-speed HG-X drivetrains
• Tire Clearance: +15 mm for shorter chainstays and better handling

Technical Details:

• Model: FD-M612-D
• Group: Shimano Deore
• Front speeds: 3-speed
• Rear speeds: 10-speed
• Total Capacity: 18 teeth
• Max. Chainring Size: 40–42 teeth
• Compatible Chain: Shimano HG-X 10-speed
• Chain Line: 50 mm
• Chainstay Angle: 66–69°
• Material: Aluminum, Steel
• Color: Black / Silver

Scope of Delivery:

• Shimano Deore FD-M612 Front Derailleur 3x10-speed Direct Mount Side-Swing
• Note: Workshop packaging (without retail packaging)

Manufacturer Article No.: KFDM612D6 | EAN: 4524667332688

Maximum shifting precision and modern technology – with the Deore FD-M612 front derailleur from Shimano!
