Modern aluminum trail frame for balanced 27.5" setups with versatile travel.

The Kona Process 134 DL Frame (Model Year 2021) in frame size XL is a robust base for a modern trail bike. Designed for 27.5" wheels with 140 mm front travel and 134 mm rear travel, the frame offers a balanced ratio of control, smooth running, and trail suitability. The grey / blue color scheme gives the frame a sporty, timeless look.

The rear triangle is designed for the Boost standard (12x148 mm), ensuring high stiffness and precise handling. With a PF92 bottom bracket and the head tube standard 44 mm top / 55.95 mm bottom, the frame complies with the common standards of the model year. Information regarding brake mount is not available and was deliberately not added.

The frame uses a seat post with a 31.6 mm diameter and a seat clamp with 34.9 mm. The specified frame weight is 3832 g.

Highlights:

• Aluminum Trail Frame (2021): robust and durable for tough trail use.
• 140 / 134 mm Travel: balanced trail performance with reserves.
• 27.5" Platform: agile and controlled on technical trails.
• Boost 12x148 mm: stiff rear triangle for precise handling.
• 31.6 mm Seat Post: compatible with common dropper posts.

Technical Data:

• Manufacturer: Kona
• Model: Process 134 DL
• Model Year: 2021
• Frame Type: Bicycle frame / frameset
• Material: Aluminum
• Frame Size: XL
• Color: grey / blue
• Inches / Wheel Size: 27.5"
• Travel: 140 mm front / 134 mm rear
• Rear Axle: 12 x 148 mm Boost
• Seat Tube / Clamp: 31.6 mm / 34.9 mm
• Bottom Bracket: PF92
• Headset / Head Tube Standard: top 44 mm / bottom 55.95 mm
• Weight: 3832 g
• EAN: 841073142231

Scope of Delivery (as pictured):

• 1 x Kona Process 134 DL Aluminum Frame | Size XL | 27.5"
• Incl. thru-axle and derailleur hanger. Without further accessories.

The Kona Process 134 DL Frame (2021) is a reliable aluminum base for a modern 27.5" trail bike with balanced travel and high everyday usability.
