Robust 28" rear wheel for road, all-road and e-bike use.
The DT Swiss HE 1800 SPLINE db 28" rear wheel with a 32 mm rim depth and 20 mm internal width is designed for reliable performance in everyday use and on long tours. The stable aluminum rim ensures efficient power transfer and clean handling on asphalt and paved roads.
The DT Swiss 370 hub with 3-pawl freehub ensures solid and durable power transfer. In combination with aerodynamically optimized DT Aero Hybrid Straightpull spokes, this creates a resilient wheelset for modern disc setups. Also approved for e-bikes up to 250 W.
Technical Data:
- Model: HE 1800 SPLINE db 32
- Version: Rear Wheel
- Size: 28" / 700C
- Rim: Aluminum, Hooked / Crotchet tubeless TC
- Rim Height: 32 mm
- Internal Width: 20 mm
- Outer Width: 24 mm
- Axle: 12x142 mm Thru Axle
- Brake Disc Mount: Centerlock
- Freehub: Shimano HG
- Hub: DT Swiss 370 with 3 Pawl
- Net Weight: 1078 g
- Max. System Weight: 130 kg
- ASTM: 2
- E-Bike Approval: Yes (up to 32 km/h / 250 W)
- Manufacturer Number: WHE1800NIDVSA11405
SKU: 1405 (W7C2)
DT Swiss HE 1800 SPLINE db Rear Wheel 28" | 20mm Inner Rim Width | 12x142mm Thru Axle | Centerlock | Shimano HG
Check compatibility
Will this wheel fit your bike?
In our short video, we explain what to look out for when checking axle size, freehub type and brake rotor mount.
Robust 28" rear wheel for road, all-road and e-bike use.
The DT Swiss HE 1800 SPLINE db 28" rear wheel with a 32 mm rim depth and 20 mm internal width is designed for reliable performance in everyday use and on long tours. The stable aluminum rim ensures efficient power transfer and clean handling on asphalt and paved roads.
The DT Swiss 370 hub with 3-pawl freehub ensures solid and durable power transfer. In combination with aerodynamically optimized DT Aero Hybrid Straightpull spokes, this creates a resilient wheelset for modern disc setups. Also approved for e-bikes up to 250 W.
Technical Data:
- Model: HE 1800 SPLINE db 32
- Version: Rear Wheel
- Size: 28" / 700C
- Rim: Aluminum, Hooked / Crotchet tubeless TC
- Rim Height: 32 mm
- Internal Width: 20 mm
- Outer Width: 24 mm
- Axle: 12x142 mm Thru Axle
- Brake Disc Mount: Centerlock
- Freehub: Shimano HG
- Hub: DT Swiss 370 with 3 Pawl
- Net Weight: 1078 g
- Max. System Weight: 130 kg
- ASTM: 2
- E-Bike Approval: Yes (up to 32 km/h / 250 W)
- Manufacturer Number: WHE1800NIDVSA11405
