High-end hub for fast road bikes & wheel builds.

The DT Swiss 180 Straightpull Ceramic Rear Hub with 130 mm installation width and 5 mm quick release is the premium basis for lightweight, stiff wheels on road bikes, gravel bikes, or aero bikes with rim brakes. Thanks to Ratchet EXP 36 and SINC Ceramic bearings, it combines extremely low rolling resistance with direct power transfer – ideal for ambitious riders, time trialists, and high-quality custom builds.

The redesigned Ratchet EXP 36 ratchet freehub reduces the number of components, increases bearing spacing, and makes the hub lighter, stiffer, and even more reliable. All teeth of the ratchets engage fully – creating a robust system with defined, direct power transmission. Maintenance and conversion are particularly easy thanks to the No-Tool concept: end caps and freehub body can be removed without tools.

The installed version comes with a SRAM XDR Road freehub body and is therefore perfectly suited for modern 12-speed SRAM road bike cassettes (XDR). The Straightpull design for 24 spoke holes ensures high lateral stiffness and even tension distribution – optimal for stiff, lightweight wheels in the performance sector. At the same time, the hub is also approved for use on e-bikes up to 32 km/h / 250 W.

Highlights:

• Ratchet EXP 36 freehub: direct engagement, high reliability, and reduced weight.
• SINC Ceramic bearings: extremely smooth-running and durable for maximum speed.
• Straightpull design: 24-hole hub for stiff, precise wheels.
• QR 130 mm & rim brake: optimal for classic road bike frames and aero bikes without disc.
• SRAM XDR Road freehub: suitable for current SRAM road and gravel cassettes.

Technical Data:

• Manufacturer: DT Swiss
• Model: 180 Straightpull Ceramic Rear Hub
• Area of use: Road bike, Gravel, Aero, E-Road (up to 32 km/h / 250 W)
• Axle system: 5 mm Quick Release (QR)
• Installation width: 130 mm
• Brake system: Rim brake (Non Disc)
• Number of holes: 24
• Spoke type: Straightpull
• Freehub system: Ratchet EXP 36
• Freehub body: SRAM XDR Road
• Compatible cassettes: SRAM XDR Road (e.g. 12-speed)
• Bearings: DT Swiss SINC Ceramic industrial bearings
• Approved for E-bikes: yes, up to 32 km/h or max. 250 W
• Color: black

Special features of Ratchet EXP:

• No-Tool concept: Disassembly of end caps and freehub without tools.
• Integrated threaded ring: fewer components, lower weight, longer lifespan.
• Greater bearing spacing: up to approx. 15% more hub stiffness compared to older systems.

Scope of delivery:

• 1 x DT Swiss 180 Straightpull Ceramic Rear Hub | 130 mm QR | Rim Brake | SRAM XDR | Ratchet EXP 36
• without quick release

Manufacturer article no.: H18PHRQ1R24SA4702S | EAN: 7613052361031 | GTIN: 7613052361031

The DT Swiss 180 Straightpull Ceramic Rear Hub is the premium choice for anyone looking to build a maximally efficient, lightweight, and reliable rim brake wheel with XDR freehub.
