High-End Performance for Your Gravity Bike: The Öhlins TTX22m.2 Coil Shock with 225 x 75 mm Trunnion Mount brings the legendary Twin-Tube system in a revised, even more powerful version to your mountain bike. Whether for Enduro racing or Bikepark sessions – this shock stands for maximum control, bottom-out resistance, and finest traction on rough terrain.
The revised bottom-out bumper improves riding performance in the mid to maximum travel range and reliably protects against harsh bottom-outs. With new adjustment options for high- and low-speed compression and rebound damping, the TTX22m.2 can be perfectly adapted to your trail and riding style. Thanks to its modular design, spring changes are also a breeze – no special tools required.
Included in the set is a high-quality steel spring with 548 lbs/in, which impresses with its low weight and high load capacity. The perfect choice for ambitious gravity riders who demand uncompromising performance.
Highlights:
- Optimized for Enduro, Gravity, and Downhill
- TTX Twin-Tube technology with excellent responsiveness
- Newly developed bottom-out protection for more control at the end of the travel
- Individually tunable – with 3x HSC, 16x LSC & LSR, 7x HSR
- Easy installation & spring change without special tools
- Completely serviceable – 2-year warranty
Technical Data:
- Shock Length: 225 mm (Trunnion)
- Stroke: 75 mm
- Mounting: Trunnion
- Spring: Steel spring 548 lbs/in – Ø 36 mm
- Type: TTX22m.2 Coil
- Material: Aluminum, hard anodized
- Color: Black/Gold (Shock), Yellow/Orange (Spring)
- Weight (Shock incl. Spring): 991 g
Adjustment Options:
- 3-position High-Speed Compression (Trail/DH/Open)
- 16-position Low-Speed Compression
- 16-position Low-Speed Rebound
- 7-position High-Speed Rebound
- Spring preload
Scope of Delivery:
- 1x Öhlins TTX22m.2 Coil Shock 225 x 75 mm Trunnion
- 1x Öhlins MTB Steel Spring 548 lbs
- Note: Workshop packaging (without outer packaging). Delivery without bushings.
Manufacturer-No.: MTBM 2252 | Spring-No.: 18075-14
For uncompromising control on every trail – with the Öhlins TTX22m.2, you're ready for any terrain!
